Yololiv YoloBox Mini Ultra-Portable All-in-One Smart Live Streaming Encoder & Monitor (EM Version)

Name: Yololiv YoloBox Mini Ultra-Portable All-in-One Smart Live Streaming Encoder & Monitor (
Brand: Yololiv
SKU: GT-0690743

Model #006

Yololiv Warranty

Greentoe Guarantee

Guaranteed Brand New Products
All Products Sold by Manufacturer Authorized Retailers
30 Day Return Policy
Free Shipping
No Additional Fees

Coming Soon!

This is a new item and not yet available for sale from anyone in our network. Click the button below and we will notify you when it becomes available.

Specifications

Specifications

Wireless

Wi-Fi

2.4/5 GHz

Power

Power Connector	1 x USB Type-C (5 to 12 VDC at 1.5 A) Input
Built-In Battery	4700 mAh

IP Encoding/Decoding

Transport Protocols	RTMP, RTMPS
IP Video	H.264: 960 x 540 to 1920 x 1080 Encoding
Compatible Services	Facebook Live, Twitch, YouTube Live
IP Audio	AAC-LC: Encoding
Simultaneous Streams	3 Streams

Internal Recording

Recording Modes	1920 x 1080p up to 60 fps
Recording Media	1 x SD (Unspecified Type)

Interfaces

Embedded Audio	HDMI/USB Type-C/Wireless: 2-Channel
Video Connectors	1 x HDMI Input 1 x HDMI Output
Audio Connectors	1 x 1/8" / 3.5 mm TRS Stereo Analog Input 1 x 1/8" / 3.5 mm TRS Mono Analog Input 1 x 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Analog Output
Other I/O	1 x RJ45 10/100 Ethernet Input/Output 1 x USB Type-A USB 3.1 Gen 1 Input 1 x USB Type-C USB 3.1 Gen 1 Input/Output

General

Weight	11.3 oz / 320 g
Dimensions	6.1 x 3.6 x 0.8" / 155 x 92.6 x 20 mm
Display	LCD

Environmental

Storage Temperature	41 to 104°F / 5 to 40°C
Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	15 to 85%

Cellular

4G LTE	LTE
SIM Card Slots	1 x Nano SIM

Product Highlights

Simultaneous Cross-Platform Streaming
Encoder, Monitor, Switcher, and Recorder
5.5" LCD Touchscreen Control
1 X HDMI Input, 1 X HDMI Output
1 X USB Input
Supports H.264/MP4 up to 1080p Video
Stream via Ethernet, Wi-Fi, 4G LTE
1 x SD Card Slot for Record, up to 128GB
HDCP Compliant, Audio & Mic Input
500 cd/m² Brightness, Built-In Battery

In The Box

YoloLiv YoloBox Mini Ultra-Portable All-in-One Smart Live Streaming Encoder & Monitor (EM Version)
USB Charger Cable
Shoe Mount
SIM Card Eject Pin
Limited 1-Year Warranty
