| Package Weight | 36.85 lb |
|---|---|
| Box Dimensions (LxWxH) | 23.5 x 17.0 x 16.5" |
| Frequency Response | 49 Hz to 20 kHz at -6 dB 47 Hz to 20 kHz at -10 dB |
|---|---|
| Nominal Coverage Angle | 75°, axisymetric |
| Max SPL | 126 dB measured at 3.3" / 1.0 m with dynamic pink noise |
| Amplifier Class | Class-D |
| Peak Power Output | LF Driver: 800 W HF Driver: 200 W |
| Controls | Power, gain, mic boost, 6-way contour selector |
| Indicators | Power, input signal, input B microphone, limiter |
| Configuration | 2-way active loudspeaker |
| Enclosure Material | Polypropylene |
| Attachment | M10 threaded insert |
| Grille | 18 Gauge powered coated steel |
| AC Power | Universal power supply, 100 to 240 VAC, 50 to 60 Hz |
| AC Power Consumption | 100 VAC, 0.75 A / 120 VAC, 1.0 A / 240 VAC 0.31 A (at 1/8 power) |
| Dimensions (H x W x D) | 20.3 x 13.8 x 12.7" / 516 x 350 x 323 mm |
| Weight | 30.3 lb / 13.7 kg |
| Connectors | 2 x XLR-1/4" combination input (line input and mic/line input, locking) 1 x 3.5 mm TRS input 1 x XLR output (mix output) |
| Transducers | LF Driver: 12.0" / 305.0 mm, cone HF Driver: 1.4" / 35.6 mm, compression driver |
