| Reticle Type | MT 308 Reticle (Second Focal Plane) |
|---|---|
| Illumination | Partially Illuminated |
| Illumination Type | LED |
| Illuminated Color | Red |
| Brightness Settings | Adjustable Brightness (512 Levels) |
| Magnification | 6 to 24x |
|---|---|
| Diopter Correction | -3.0 to +3.0 |
| Objective Lens Diameter | 56 mm |
| Field of View | 6x: 17.8' @ 100 yd / 5.9 m @ 100 m 24x: 4.8' @ 100 yd / 1.6 m @ 100 m |
| Exit Pupil Diameter | 6x: 9.1 mm 24x: 2.3 mm |
| Eye Relief | 3.5 to 3.1" / 8.9 to 8 cm |
| Weight | 30.6 oz / 868 g |
|---|---|
| Maintube Diameter | 30 mm |
| Battery | 1 x CR2354 |
| Material | Aluminum |
| Dimensions | Length: 15.2" / 38.6 cm |
| Parallax Correction | Yes, 27.4 yd / 25 m |
|---|---|
| Filter Thread | M59 x 0.75 |
| Impact Point Correction | 1/4 MOA per Click |
| Windage Adjustment | 44 MOA |
| Elevation Adjustment | 87 MOA |
| Water Resistance | Waterproof |
|---|---|
| Fogproof | Yes, Nitrogen Filled |
| Operating Temperature | -40 to 131°F / -40 to 55°C |
| Storage Temperature | -49 to 159°F / -45 to 71°C |
| Operating Humidity | 98% |
