| Package Weight | 52.0 lb |
|---|---|
| Box Dimensions (LxWxH) | 27.0 x 17.0 x 17.0" |
| Crossover Frequency | 1.7 kHz |
|---|---|
| Enclosure Material | 15 mm Plywood with EVCoat |
| Frequency Response | -10 dB: 50 Hz - 20 kHz -3 dB: 60 Hz - 18 kHz 1 Please Note: Hz Full space measurement using the music DSP preset. close |
| Grille | 18 AWG steel with powdercoat |
| Transducer | HF: DH-1M 1" titanium compression driverLF: EVS-12M 12" (300 mm) |
| Connectors | 1 x RCA, stereo input2 x XLR/TRS combo jack1 x XLR, link output |
| Power Consumption | 1.8 ACurrent rating is 1/8 power |
| Power Rating | 1500 W |
| Suspension | 8 x M10 threaded mounting points |
| Dimensions | 23.9 x 14.76 x 14.02" (60.7 x 37.5 x 35.6 cm) |
| Weight | 18.8 kg (41.45 lb) |
| Maximum SPL | 132 dB 2 Please Note: 132 dB maximum SPL is measured at 3.3' (1 m) using broadband pink noise at maximum output close |
| Coverage | Nominal: -6 dBHorizontal: 90°Vertical: 60° |
