Nikon D500 DSLR Camera with 16-80mm Lens
Model: 1560








| Viewfinder Magnification | Approx. 1.0x |
|---|---|
| Diagonal Angle of View | 170.0° |
| Screen Coverage | 100% |
| Display Screen | 3.2" Rear Touchscreen Tilting LCD (2,359,000) |
| Diopter Adjustment | - 2 to +1 m |
| Viewfinder Type | Pentaprism |
| Viewfinder Eye Point | 16.00 mm |
| Viewfinder Coverage | 100% |
| AC Power Adapter | EH-5b (Optional) |
|---|---|
| Battery | 1x EN-EL15 Rechargeable Lithium-ion Battery Pack, 7 VDC, 1900 mAh |
| Operating/Storage Temperature | Operating32 to 104°F (0 to 40°C)Humidity: 85 - 0% |
| Weight | 1.89 lb / 860 g with battery and memory card |
|---|---|
| Dimensions (WxHxD) | 5.8 x 4.5 x 3.2" / 147.0 x 115.0 x 81.0 mm |
| Connectivity | 1/8" Headphone, 1/8" Microphone, HDMI C (Mini), Micro-USB, NIkon 10-Pin, USB 3.0 |
|---|---|
| Self Timer | 20 seconds, 10 seconds, 5 seconds, 2 seconds |
| Continuous Shooting | Up to 10 fps |
| Wi-Fi Capable | Yes |
| Interval Recording | Yes |
| Weight | 1.06 lb (480 g) |
|---|---|
| Focal Length | 16 - 80mm Comparable 35mm Focal Length: 24 - 120 mm |
| Aperture | Maximum: f/2.8 - 4Minimum: f/22 - 32 |
| Angle of View | 84° - 20° |
| Minimum Focus Distance | 1.15' (35 cm) |
| Magnification | 0.22x |
| Elements/Groups | 17/13 |
| Diaphragm Blades | 7, Rounded |
| Autofocus | Yes |
| Image Stabilization | Yes |
| Filter Thread | Front: 72 mm |
| Dimensions (DxL) | Approx. 3.15 x 3.37" (80 x 85.5 mm) |
| Aspect Ratio | 3:2 |
|---|---|
| Memory Card Type | SDSDHCSDXCXQD |
| Lens Mount | Nikon F |
| Camera Format | DX / (1.5x Crop Factor) |
| Pixels | Actual: 21.51 MegapixelEffective: 20.9 Megapixel |
| Max Resolution | 5568 x 3712 |
| Dust Reduction System | Yes |
| Bit Depth | 14-bit |
| File Formats | Still Images: JPEG, RAW, TIFFMovies: MOV, MPEG-4 AVC/H.264Audio: Linear PCM (Stereo) |
| Sensor Type / Size | CMOS, 23.5 x 15.7 mm |
| Autofocus Points | Phase Detection:153, 99 cross-type |
|---|---|
| Focus Type | Auto & Manual |
| Focus Mode | Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S) |
| Flash Compensation | -3 EV to +1 EV (in 1/3, 1/2 or 1 EV steps) |
|---|---|
| Flash Modes | 1st Curtain SyncHi-Speed SyncOffRear Curtain/Slow SyncRear SyncRed-eye ReductionSlow SyncSlow Sync/Red-eye Reduction |
| External Flash Connection | Hot Shoe, PC Terminal |
| Dedicated Flash System | iTTL |
| Built-in Flash | No |
| Max Sync Speed | 1 / 250 seconds |
| Continuous Shooting | Up to 10 fps at 20.9 MP for up to 200 frames in raw format |
|---|---|
| ISO Sensitivity | Auto, 100-51200 (Extended Mode: 50-1640000) |
| Shutter | Type: Electronic & MechanicalSpeed: 30 - 1/8000 second |
| Remote Control | WR-R10, WR-1 (Optional) |
| Mirror Lock-Up | Yes |
| Metering Method | 3D Color Matrix Metering, Center-weighted average metering, Spot metering, Highlight Weighted |
| Exposure Modes | Modes: Aperture Priority, Manual, Program, Shutter PriorityMetering Range: EV -4.0 - EV 20.0Compensation: -5 EV to +5 EV (in 1/3, 1/2 or 1 EV steps) |
| White Balance Modes | Auto, Cloudy, Color Temperature, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade |
| Video Recording | Yes, NTSC |
|---|---|
| Audio Recording | Built-in Mic: With Video, StereoOptional External Mic: With Video, Stereo |
| Video Clip Length | 3840 x 2160@ 30 fps: 3 min.1920 x 1080@ 60 fps: 20 min.1920 x 1080@ 30 fps: 29 min. 59 seconds |
| Focus | ManualContinuous Auto |
| ISO Sensitivity | Auto/Manual, 100 - 51200, Expandable to 1640000 |
| Exposure Control | Manual: Shutter Speed, Aperture, ISO |
| Aspect Ratio | 16:9 |
| Video Format | 4KMPEG4-AVC/H.2643840 x 2160p / 30 fps3840 x 2160p / 25 fps3840 x 2160p / 24 fpsHigh DefinitionMPEG AVC/H.2641920 x 1080p / 60 fps1920 x 1080p / 50 fpsHigh DefinitionMPEG AVC/H.2641920 x 1080p / 30 fps1920 x 1080p / 25 fps1920 x 1080p / 24 fpsHigh DefinitionMPEG AVC/H.2641280 x 720p / 60 fps1280 x 720p / 50 fps |
