dbx 231s - Graphic EQ

Model #231S EQ

DBX Warranty
Dbx 231s eq 1
Dbx 231s eq 1
Dbx 231s eq 2
Dbx 231s eq 3
How it works
  • You name the price you want to pay for a product.
  • We send your offer to a network of Certified Retailers.
  • If the retailer likes your offer, you get that price for the product.
Greentoe Guarantee
  • All Products are New and from Manufacturer Authorized Retailers
  • 30 day return policy
  • Free Shipping
    No Additional Fees

Name your price

ON A BRAND NEW DBX 231S EQ

Lowest Price Online: $219.00 ?

ENTER YOUR PRICE

$
Your Chances of Success
lowest price online $219.00
average price online $219.00

Your chances of success

Online Prices
We have done the shopping for you! Here is a list of the lowest prices currently found online. With Greentoe, the price will be lower than these prices. “Name Your Price” and find out.
Enter your zip code to see how much we will be saving you!
Showing prices for zip code 94103 change
Retailer Base Price Tax Shipping Total
Amazon logo $219.00 $0.00 $0.00 $219.00
**Pricing is for informational purposes. Not all retailers have direct relationship with Greentoe.
Specifications

Packaging Info

Package Weight 8.1 lb
Box Dimensions (LxWxH) 21.7 x 11.3 x 4.8"

General Information

Frequency Bands 31
Bandwidth 1/3-octave
Range (Boost/Cut) +/-6dB or +/-12 dB, switchable
Inputs 2 x XLR (pin 2 hot)2 x 1/4" TRS phone 1 Please Note: Electronically balanced/unbalanced, RF filtered close
Input Impedance 40kΩ balanced, 20kΩ unbalanced
Maximum Input Level >+21dBu balanced or unbalanced
Outputs 2 x XLR (pin 2 hot)2 x 1/4" TRS phone 2 Please Note: Electronically balanced/unbalanced, RF filtered close
Output Impedance 100Ω balanced, 50Ω unbalanced
Maximum Output Level >+21dBu balanced/unbalanced into 2kΩ or greater>+18dBm balanced/unbalanced into 600Ω
Frequency Response FR: 50kHz, +0.5/-3.0dBBandwidth: 20Hz to 20kHz, +0.5/-1.0dB
Filter Type Graphic, constant Q
Noise SNR: >95dB typical
THD + N
Crosstalk
CMRR >40dB, typically >55dB @ 1kHz
Switches EQ Bypass - bypasses the graphic equalizer section in the signal path Low Cut - activates the 50Hz 12dB/octave high-pass filter Range - selects either +/- 6dB or +/-12dB slider boost/cut range
Power Requirements 100~240VAC 50/60Hz15W power consumption
Dimensions (WxHxD) 19 x 6 x 3.5" (483 x 152 x 89mm)
Weight 6.2 lb (2.8kg)
Specialties 20mm non-conductive sliders
Dynamic Range >112dB typical
Number of Channels 2
Product Highlights
  • Dual Channel
  • 2 x 31-Band
  • 1/3 Octave
  • Switchable Boost/Cut Range
  • 20mm Sliders
  • 4-Segment LED Ladders
