dbx 1231 - Dual Channel 31-Band Graphic Equalizer with 6 or 15 dB Switchable Boost/Cut and RF Filtered I/Os
Model #1231
DBX Warranty


- You name the price you want to pay for a product.
- If the retailer likes your offer, you get that price for the product.
- All Products are New and from Manufacturer Authorized Retailers
- 30 day return policy
-
Free Shipping
No Additional Fees
Product Back-Ordered
We are sorry. At this time, we are not accepting offers on this product. Please click the button below to be notified when our retailers get it back in stock.
Thank you! We will be in touch.
Something went wrong. Please try again later.
Specifications
Packaging Info
Package Weight | 13.84 lb |
Box Dimensions (LxWxH) | 22.5 x 11.5 x 7.6" |
General Information
Inputs | 2 x XLR, 2 x 1/4" TRS phone, barrier strip |
Output | 2 x XLR, 2 x 1/4" TRS phone, barrier strip |
Maximum Input Level | +21dBu |
Frequency Bands | 31 x 2, ISO spacing |
Bandwidth | 1/3 octave |
Range (Boost/Cut) | +/-6dB or +/-15dB selectable |
Filter Type | Graphic |
Frequency Response | 10Hz to 50kHz |
Dynamic Range | 115dB |
Noise | -97dBu |
Dimensions | 3U rack, 7 15/16" deep |
Specialties | Power-off hardwire relay bypass with 2-second power-up delay |
Maximum Output Level | +21dBu |
Number of Channels | 2 |
