dbx 1074 QuadGate - Four Channel Noise Gate
Model: 1074








| Package Weight | 8.7 lb |
|---|---|
| Box Dimensions (LxWxH) | 22.2 x 11.5 x 3.7" |
| Inputs | 4 x XLR (2-pin hot)4 x 1/4" TRS phone Key Input |
|---|---|
| Outputs | 4 x XLR (2-pin hot) |
| Maximum Input Level | >+22dBu balanced or unbalanced |
| Compression Threshold | Not applicable |
| Compression Ratio | Not applicable |
| Attack Time | Not applicable |
| Release Time | Not applicable |
| Gate Threshold | Off to -10dB |
| Function | Noise gate |
| Maximum Output Level | >+22dBm balanced, >+20dBm unbalanced |
| Make-up Gain | Not applicable |
| Frequency Response | 0.35Hz to 200kHz, +0/-3dB |
| Dynamic Range | >115 dB, unweighted |
| Noise | |
| Dimensions (WxDxH) | 19" x 9" x 1 3/4" |
| Weight | 6.9 lbs |
| Specialties | Switchable filter control allows the user to select the frequency at which gating occurs with ranges from 80Hz to 8kHz |
| Gate Rate | Release: 0.01 to 3 seconds |
| Number of Channels | 4 |
