Blackmagic design ATEM SDI Extreme ISO Switcher

Name: Blackmagic design ATEM SDI Extreme ISO Switcher
Brand: Blackmagic Design
SKU: GT-0756222
Price: 1495.0 USD
Availability: OutOfStock

Model: SWATEMMXEPCEXTISO

Blackmagic Design Warranty

Greentoe Guarantee

Guaranteed Brand New Products
All Products Sold by Manufacturer Authorized Retailers
30 Day Return Policy
Free Shipping
No Additional Fees

Product Unavailable

We are sorry. At this time, we are not accepting offers on this product.

Specifications

Specifications

Processing

Switching Type

IR Remote, Pushbutton, Software

Packaging Info

Box Dimensions (LxWxH)	21.1 x 10.7 x 2.6"
Package Weight	4.98 lb

Output

Multiview Output	Yes
Embedded Audio Output	SDI: 2-Channel (per Output)
Output Audio Format	Analog
Audio Outputs	1x 1/8" / 3.5 mm TRS Analog
Output Video Format	SDI (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps USB-C (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
Video Outputs	4x BNC (3G-SDI) (Program) 2x USB-C
Video Output Channels	6

Input

Audio Inputs	2x 1/8" / 3.5 mm TRS Stereo Analog Female
Input Audio Format	Analog
Number of Video Input Sources	8
Embedded Audio Input	SDI: 2-Channel (per Input)
Video Inputs	8x BNC (3G-SDI)
Input Video Format	SDI (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 56/59.94/60 fps 720p at 50/59.94/60 fps

Hardware

Wi-Fi	No
Processor	Not Specified by Manufacturer
OS Compatibility	macOS 11 macOS 12 or Later Windows 10 Windows 11
Operating System	macOS, Windows 10 Home, Windows 11 Home
Power Consumption	Device: 36 W
Power I/O	1x Barrel (12 VDC) Input
Bluetooth	No

General Information

Available M/E Layers	9 M/E
Audio Mixing	2-Channel Mixing
Generators	5x Pattern 2x Color
Effect Types	DVE, Transition, Chroma Key, Luma Key

General

Weight	3.13 lb / 1.42 kg
Dimensions	14.56 x 5.94 x 1.56" / 36.98 x 15.09 x 3.96 cm

Environmental

Operating Humidity	0 to 90%
Storage Temperature	14 to 140°F / -10 to 60°C
Operating Temperature	37 to 72°F / 5 to 40°C

Connectivity

Other I/O	1x RJ45 Control Input/Output
IP Video	1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p Encoding
HDCP Support	No

Product Highlights

8-Channel 3G-SDI Live Streaming Switcher
Supports up to 1080p60
RTMP Streaming via Ethernet or USB-C
Record Program Out and Individual Inputs
11-Input, 2-Channel Audio Mixer
Input Frame Rate and Format Converter
Re-Sync on All 3G-SDI Inputs
HD Multiview Output with up to 16 Views
Local and Software Switching
4 x Upstream, 2 x Downstream Keyers

In The Box

Blackmagic Design ATEM SDI Extreme ISO Switcher
Power Supply
Limited 1-Year Manufacturer Warranty
